WGSL limits you won't find in the spec
Hunting for the unknown WebGPU shader limits
Welcome back, in my last post I did an evaluation of the WebGPU shader limits that we are told about in the WGSL spec.
Having tested only the known shader limits in the spec in that previous post, this time I want to go a bit away from it.
For this post I want to take a look at the limits we have when writing a WGSL shader that cannot be found in the spec.
Some of these experiments I tried purely for fun, hoping to stumble on a creative angle. Others are just fresh findings.
In retrospect this feels a bit like off-road terrain that nobody cares about, these are limits after all, so fasten the seatbelt and let's take a ride.
Setup
Tests were run on macOS 15.6.1 on an Intel Mac equipped with both Intel and AMD GPUs. The reported adapter vendor is "Intel" and architecture is "gen-9".
All code is run in a webworker in an offline canvas, with a WebGPU DSL that I have been cooking as a creative tool to maybe produce something in time for Inércia Demoparty 2025.
This home-made DSL allows macros to define all parts of the WebGPU plumbing (more on that in the next posts).
1 - The main unknown practical limit
When composing a big WGSL shader the main limit we have to consider is How big can a JS string actually get?
After all, WebGPU is somewhat tied to JS from a portability angle. The string length section of MDN puts it nicely:
The language specification requires strings to have a maximum length of 253 - 1 elements, which is the upper limit for precise integers. However, a string with this length needs 16384TiB of storage, which cannot fit in any reasonable device's memory, so implementations tend to lower the threshold, which allows the string's length to be conveniently stored in a 32-bit integer.
- In V8 (used by Chrome and Node), the maximum length is 229 - 24 (~1GiB). On 32-bit systems, the maximum length is 228 - 16 (~512MiB).
- In Firefox, the maximum length is 230 - 2 (~2GiB)...
- In Safari, the maximum length is 231 - 1 (~4GiB).
It's nice to see Safari upping the limits.
That MDN article is very interesting, with theory and code examples on how to
get to these limits. For my purposes I am going to assume that we are dealing
with a safe limit of 512MiB.
That's a big shader!
I don't expect to hit this limit on my tests because I am using JSON.stringify
on the shader string to send it together with metadata to my DSL engine WebGPU
player. The stringify() function itself acts as a memory barrier for such huge
strings.
Within this constraint, what other limits are waiting for us?
2 - Express your self syntax errors
How big can an expression be in WGSL? let's find out:
// How big can we make this turn out to be?
var result: f32 = 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + ... + ???;
For this test I created a small harness to expand the expression up to "n" sums.
The results turned out to be consistent in both Safari and Chrome:
Safari Technology Preview 227
Chrome 140.0.7339.133
Surprisingly consistent, even the error message is almost exactly the same.
3 - This is not LISP
What if we create the expression like this instead:
// How many parentheses can we push here?
var result: f32 = 0.0 + (1.0 + (2.0 + (3.0 + (4.0 + ... + ??? )))))...);
And again the results turned out to be consistent in both Safari and Chrome:
Safari Technology Preview 227
Chrome 140.0.7339.133
This time even the error message is exactly the same.
4 - Brackets? what brackets?
Now that we know these limits, let's try to create two of these, but chained together, what could possibly go wrong?
var result1: f32 = 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + ... + 511.0;
// and lets place result1 here:
var result2: f32 = result1 + 1.0 + 2.0 + 3.0 + 4.0 + ... + 511.0;
The results are surprising, but on the other end of the surprise:
Safari Technology Preview 227
Chrome 140.0.7339.133
Chrome error message is intriguing. You can see it all if you want by clicking down below.
Full Chrome Error Message (very long)
ShaderModuleMTL: Unable to create library object: program_source:33:271: fatal error: bracket nesting level exceeded maximum of 256
program_source:33:271: note: use -fbracket-depth=N to increase maximum nesting level
from produced MSL shader below:
#ifdef __clang__
#pragma clang diagnostic ignored "-Wall"
#endif
#pragma METAL fp math_mode(relaxed) #include <metal_stdlib> using namespace
metal;
template<typename T, size_t N> struct tint_array { const constant T&
operator[](size_t i) const constant { return elements[i]; } device T&
operator[](size_t i) device { return elements[i]; } const device T&
operator[](size_t i) const device { return elements[i]; } thread T&
operator[](size_t i) thread { return elements[i]; } const thread T&
operator[](size_t i) const thread { return elements[i]; } threadgroup T&
operator[](size_t i) threadgroup { return elements[i]; } const threadgroup T&
operator[](size_t i) const threadgroup { return elements[i]; } T elements[N]; };
struct tint_struct { device tint_array<float, 1>* tint_member; const constant
tint_array<uint4, 1>* tint_member_1; };
struct tint_struct_1 { uint tint_member_2; };
float v() { float v_1 = 129795.0f; float v_2 =
(((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((((v_1 +
1.0f) + 2.0f) + 3.0f) + 4.0f) + 5.0f) + 6.0f) + 7.0f) + 8.0f) + 9.0f) + 10.0f) +
11.0f) + 12.0f) + 13.0f) + 14.0f) + 15.0f) + 16.0f) + 17.0f) + 18.0f) + 19.0f) +
20.0f) + 21.0f) + 22.0f) + 23.0f) + 24.0f) + 25.0f) + 26.0f) + 27.0f) + 28.0f) +
29.0f) + 30.0f) + 31.0f) + 32.0f) + 33.0f) + 34.0f) + 35.0f) + 36.0f) + 37.0f) +
38.0f) + 39.0f) + 40.0f) + 41.0f) + 42.0f) + 43.0f) + 44.0f) + 45.0f) + 46.0f) +
47.0f) + 48.0f) + 49.0f) + 50.0f) + 51.0f) + 52.0f) + 53.0f) + 54.0f) + 55.0f) +
56.0f) + 57.0f) + 58.0f) + 59.0f) + 60.0f) + 61.0f) + 62.0f) + 63.0f) + 64.0f) +
65.0f) + 66.0f) + 67.0f) + 68.0f) + 69.0f) + 70.0f) + 71.0f) + 72.0f) + 73.0f) +
74.0f) + 75.0f) + 76.0f) + 77.0f) + 78.0f) + 79.0f) + 80.0f) + 81.0f) + 82.0f) +
83.0f) + 84.0f) + 85.0f) + 86.0f) + 87.0f) + 88.0f) + 89.0f) + 90.0f) + 91.0f) +
92.0f) + 93.0f) + 94.0f) + 95.0f) + 96.0f) + 97.0f) + 98.0f) + 99.0f) +
100.0f) + 101.0f) + 102.0f) + 103.0f) + 104.0f) + 105.0f) + 106.0f) + 107.0f) +
108.0f) + 109.0f) + 110.0f) + 111.0f) + 112.0f) + 113.0f) + 114.0f) + 115.0f) +
116.0f) + 117.0f) + 118.0f) + 119.0f) + 120.0f) + 121.0f) + 122.0f) + 123.0f) +
124.0f) + 125.0f) + 126.0f) + 127.0f) + 128.0f) + 129.0f) + 130.0f) + 131.0f) +
132.0f) + 133.0f) + 134.0f) + 135.0f) + 136.0f) + 137.0f) + 138.0f) + 139.0f) +
140.0f) + 141.0f) + 142.0f) + 143.0f) + 144.0f) + 145.0f) + 146.0f) + 147.0f) +
148.0f) + 149.0f) + 150.0f) + 151.0f) + 152.0f) + 153.0f) + 154.0f) + 155.0f) +
156.0f) + 157.0f) + 158.0f) + 159.0f) + 160.0f) + 161.0f) + 162.0f) + 163.0f) +
164.0f) + 165.0f) + 166.0f) + 167.0f) + 168.0f) + 169.0f) + 170.0f) + 171.0f) +
172.0f) + 173.0f) + 174.0f) + 175.0f) + 176.0f) + 177.0f) + 178.0f) + 179.0f) +
180.0f) + 181.0f) + 182.0f) + 183.0f) + 184.0f) + 185.0f) + 186.0f) + 187.0f) +
188.0f) + 189.0f) + 190.0f) + 191.0f) + 192.0f) + 193.0f) + 194.0f) + 195.0f) +
196.0f) + 197.0f) + 198.0f) + 199.0f) + 200.0f) + 201.0f) + 202.0f) + 203.0f) +
204.0f) + 205.0f) + 206.0f) + 207.0f) + 208.0f) + 209.0f) + 210.0f) + 211.0f) +
212.0f) + 213.0f) + 214.0f) + 215.0f) + 216.0f) + 217.0f) + 218.0f) + 219.0f) +
220.0f) + 221.0f) + 222.0f) + 223.0f) + 224.0f) + 225.0f) + 226.0f) + 227.0f) +
228.0f) + 229.0f) + 230.0f) + 231.0f) + 232.0f) + 233.0f) + 234.0f) + 235.0f) +
236.0f) + 237.0f) + 238.0f) + 239.0f) + 240.0f) + 241.0f) + 242.0f) + 243.0f) +
244.0f) + 245.0f) + 246.0f) + 247.0f) + 248.0f) + 249.0f) + 250.0f) + 251.0f) +
252.0f) + 253.0f) + 254.0f) + 255.0f) + 256.0f) + 257.0f) + 258.0f) + 259.0f) +
260.0f) + 261.0f) + 262.0f) + 263.0f) + 264.0f) + 265.0f) + 266.0f) + 267.0f) +
268.0f) + 269.0f) + 270.0f) + 271.0f) + 272.0f) + 273.0f) + 274.0f) + 275.0f) +
276.0f) + 277.0f) + 278.0f) + 279.0f) + 280.0f) + 281.0f) + 282.0f) + 283.0f) +
284.0f) + 285.0f) + 286.0f) + 287.0f) + 288.0f) + 289.0f) + 290.0f) + 291.0f) +
292.0f) + 293.0f) + 294.0f) + 295.0f) + 296.0f) + 297.0f) + 298.0f) + 299.0f) +
300.0f) + 301.0f) + 302.0f) + 303.0f) + 304.0f) + 305.0f) + 306.0f) + 307.0f) +
308.0f) + 309.0f) + 310.0f) + 311.0f) + 312.0f) + 313.0f) + 314.0f) + 315.0f) +
316.0f) + 317.0f) + 318.0f) + 319.0f) + 320.0f) + 321.0f) + 322.0f) + 323.0f) +
324.0f) + 325.0f) + 326.0f) + 327.0f) + 328.0f) + 329.0f) + 330.0f) + 331.0f) +
332.0f) + 333.0f) + 334.0f) + 335.0f) + 336.0f) + 337.0f) + 338.0f) + 339.0f) +
340.0f) + 341.0f) + 342.0f) + 343.0f) + 344.0f) + 345.0f) + 346.0f) + 347.0f) +
348.0f) + 349.0f) + 350.0f) + 351.0f) + 352.0f) + 353.0f) + 354.0f) + 355.0f) +
356.0f) + 357.0f) + 358.0f) + 359.0f) + 360.0f) + 361.0f) + 362.0f) + 363.0f) +
364.0f) + 365.0f) + 366.0f) + 367.0f) + 368.0f) + 369.0f) + 370.0f) + 371.0f) +
372.0f) + 373.0f) + 374.0f) + 375.0f) + 376.0f) + 377.0f) + 378.0f) + 379.0f) +
380.0f) + 381.0f) + 382.0f) + 383.0f) + 384.0f) + 385.0f) + 386.0f) + 387.0f) +
388.0f) + 389.0f) + 390.0f) + 391.0f) + 392.0f) + 393.0f) + 394.0f) + 395.0f) +
396.0f) + 397.0f) + 398.0f) + 399.0f) + 400.0f) + 401.0f) + 402.0f) + 403.0f) +
404.0f) + 405.0f) + 406.0f) + 407.0f) + 408.0f) + 409.0f) + 410.0f) + 411.0f) +
412.0f) + 413.0f) + 414.0f) + 415.0f) + 416.0f) + 417.0f) + 418.0f) + 419.0f) +
420.0f) + 421.0f) + 422.0f) + 423.0f) + 424.0f) + 425.0f) + 426.0f) + 427.0f) +
428.0f) + 429.0f) + 430.0f) + 431.0f) + 432.0f) + 433.0f) + 434.0f) + 435.0f) +
436.0f) + 437.0f) + 438.0f) + 439.0f) + 440.0f) + 441.0f) + 442.0f) + 443.0f) +
444.0f) + 445.0f) + 446.0f) + 447.0f) + 448.0f) + 449.0f) + 450.0f) + 451.0f) +
452.0f) + 453.0f) + 454.0f) + 455.0f) + 456.0f) + 457.0f) + 458.0f) + 459.0f) +
460.0f) + 461.0f) + 462.0f) + 463.0f) + 464.0f) + 465.0f) + 466.0f) + 467.0f) +
468.0f) + 469.0f) + 470.0f) + 471.0f) + 472.0f) + 473.0f) + 474.0f) + 475.0f) +
476.0f) + 477.0f) + 478.0f) + 479.0f) + 480.0f) + 481.0f) + 482.0f) + 483.0f) +
484.0f) + 485.0f) + 486.0f) + 487.0f) + 488.0f) + 489.0f) + 490.0f) + 491.0f) +
492.0f) + 493.0f) + 494.0f) + 495.0f) + 496.0f) + 497.0f) + 498.0f) + 499.0f) +
500.0f) + 501.0f) + 502.0f) + 503.0f) + 504.0f) + 505.0f) + 506.0f) + 507.0f) +
508.0f) + 509.0f); return v_2; }
void v_3(uint3 v_4, tint_struct v_5) { uint const v_6 =
(tint_struct_1{.tint_member_2=((_v_5.tint_member_1)[0u].x / 4u)}.tint_member_2 -
1u); device float_ const v_7 = (&(*v_5.tint_member)[min(uint(0), v_6)]); (*v_7)
= v(); }
kernel void
dawn_entry_point_687474703a2f2f6c6f63616c686f737420687474703a2f2f6c6f63616c686f7374(uint3
v_9 [[thread_position_in_grid]], device tint_array<float, 1>* v_10
[[buffer(0)]], const constant tint_array<uint4, 1>* v_11 [[buffer(30)]]) {
tint_struct const v_12 = tint_struct{.tint_member=v_10, .tint_member_1=v_11};
v_3(v_9, v_12); }
- While initializing [ComputePipeline "someComputation"]
My take on this is that since WebGPU is running on top of Metal (my case, i'm on a mac), WGSL gets compiled to the Metal Shading Language (MSL), and the MSL compiler has a bracket issue.
The bracket issue seems to be happening because the compiler is inserting
excessive parentheses in the second expression. It seems smart enough to
recognize that the first expression can be calculated in compile time, and dumps
the result of it instantly in v_1. However the second expression is crippled
by parenthesis way beyond its limit to process them (maybe to guarantee some
execution order when transpiling? why wasn't it smart enough to go full compile
time here as well?).
Safari simply failed to compile in this case.
5 - Still expressions
Digging into this a bit further. How many maxed expressions that do not depend on each other can we place in a function?
My approach to test this while avoiding the nasty bracket error from the previous test is to accumulate the result in a temporary variable. Then see how many of these accumulations we can get away with.
var tmp: f32 = 0.0;
tmp += 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + ... + 511.0;
tmp += 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + ... + 511.0;
...
tmp += 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + ... + 511.0;
Safari Technology Preview 227
Chrome 140.0.7339.133
A small remark about Chrome is that for higher limits (>4000), the whole macOS screen blinks dark and browser starts reporting that WebGPU is not supported.
For Safari if you are interested here is the minimal shader that breaks it.
Minimal shader that breaks Safari
@group(0) @binding(0) var<storage, read_write> output: array<f32>;
fn someFunction() -> f32 {
var tmp: f32 = 0.0;
var result0: f32 = 0.0 + 1.0 + 2.0 + 3.0 + 4.0 + 5.0 + 6.0 + 7.0 + 8.0 + 9.0 + 10.0 + 11.0 + 12.0 + 13.0 + 14.0 + 15.0 + 16.0 + 17.0 + 18.0 + 19.0 + 20.0 + 21.0 + 22.0 + 23.0 + 24.0 + 25.0 + 26.0 + 27.0 + 28.0 + 29.0 + 30.0 + 31.0 + 32.0 + 33.0 + 34.0 + 35.0 + 36.0 + 37.0 + 38.0 + 39.0 + 40.0 + 41.0 + 42.0 + 43.0 + 44.0 + 45.0 + 46.0 + 47.0 + 48.0 + 49.0 + 50.0 + 51.0 + 52.0 + 53.0 + 54.0 + 55.0 + 56.0 + 57.0 + 58.0 + 59.0 + 60.0 + 61.0 + 62.0 + 63.0 + 64.0 + 65.0 + 66.0 + 67.0 + 68.0 + 69.0 + 70.0 + 71.0 + 72.0 + 73.0 + 74.0 + 75.0 + 76.0 + 77.0 + 78.0 + 79.0 + 80.0 + 81.0 + 82.0 + 83.0 + 84.0 + 85.0 + 86.0 + 87.0 + 88.0 + 89.0 + 90.0 + 91.0 + 92.0 + 93.0 + 94.0 + 95.0 + 96.0 + 97.0 + 98.0 + 99.0 + 100.0 + 101.0 + 102.0 + 103.0 + 104.0 + 105.0 + 106.0 + 107.0 + 108.0 + 109.0 + 110.0 + 111.0 + 112.0 + 113.0 + 114.0 + 115.0 + 116.0 + 117.0 + 118.0 + 119.0 + 120.0 + 121.0 + 122.0 + 123.0 + 124.0 + 125.0 + 126.0 + 127.0 + 128.0 + 129.0 + 130.0 + 131.0 + 132.0 + 133.0 + 134.0 + 135.0 + 136.0 + 137.0 + 138.0 + 139.0 + 140.0 + 141.0 + 142.0 + 143.0 + 144.0 + 145.0 + 146.0 + 147.0 + 148.0 + 149.0 + 150.0 + 151.0 + 152.0 + 153.0 + 154.0 + 155.0 + 156.0 + 157.0 + 158.0 + 159.0 + 160.0 + 161.0 + 162.0 + 163.0 + 164.0 + 165.0 + 166.0 + 167.0 + 168.0 + 169.0 + 170.0 + 171.0 + 172.0 + 173.0 + 174.0 + 175.0 + 176.0 + 177.0 + 178.0 + 179.0 + 180.0 + 181.0 + 182.0 + 183.0 + 184.0 + 185.0 + 186.0 + 187.0 + 188.0 + 189.0 + 190.0 + 191.0 + 192.0 + 193.0 + 194.0 + 195.0 + 196.0 + 197.0 + 198.0 + 199.0 + 200.0 + 201.0 + 202.0 + 203.0 + 204.0 + 205.0 + 206.0 + 207.0 + 208.0 + 209.0 + 210.0 + 211.0 + 212.0 + 213.0 + 214.0 + 215.0 + 216.0 + 217.0 + 218.0 + 219.0 + 220.0 + 221.0 + 222.0 + 223.0 + 224.0 + 225.0 + 226.0 + 227.0 + 228.0 + 229.0 + 230.0 + 231.0 + 232.0 + 233.0 + 234.0 + 235.0 + 236.0 + 237.0 + 238.0 + 239.0 + 240.0 + 241.0 + 242.0 + 243.0 + 244.0 + 245.0 + 246.0 + 247.0 + 248.0 + 249.0 + 250.0 + 251.0 + 252.0 + 253.0 + 254.0 + 255.0 + 256.0 + 257.0 + 258.0 + 259.0 + 260.0 + 261.0 + 262.0 + 263.0 + 264.0 + 265.0 + 266.0 + 267.0 + 268.0 + 269.0 + 270.0 + 271.0 + 272.0 + 273.0 + 274.0 + 275.0 + 276.0 + 277.0 + 278.0 + 279.0 + 280.0 + 281.0 + 282.0 + 283.0 + 284.0 + 285.0 + 286.0 + 287.0 + 288.0 + 289.0 + 290.0 + 291.0 + 292.0 + 293.0 + 294.0 + 295.0 + 296.0 + 297.0 + 298.0 + 299.0 + 300.0 + 301.0 + 302.0 + 303.0 + 304.0 + 305.0 + 306.0 + 307.0 + 308.0 + 309.0 + 310.0 + 311.0 + 312.0 + 313.0 + 314.0 + 315.0 + 316.0 + 317.0 + 318.0 + 319.0 + 320.0 + 321.0 + 322.0 + 323.0 + 324.0 + 325.0 + 326.0 + 327.0 + 328.0 + 329.0 + 330.0 + 331.0 + 332.0 + 333.0 + 334.0 + 335.0 + 336.0 + 337.0 + 338.0 + 339.0 + 340.0 + 341.0 + 342.0 + 343.0 + 344.0 + 345.0 + 346.0 + 347.0 + 348.0 + 349.0 + 350.0 + 351.0 + 352.0 + 353.0 + 354.0 + 355.0 + 356.0 + 357.0 + 358.0 + 359.0 + 360.0 + 361.0 + 362.0 + 363.0 + 364.0 + 365.0 + 366.0 + 367.0 + 368.0 + 369.0 + 370.0 + 371.0 + 372.0 + 373.0 + 374.0 + 375.0 + 376.0 + 377.0 + 378.0 + 379.0 + 380.0 + 381.0 + 382.0 + 383.0 + 384.0 + 385.0 + 386.0 + 387.0 + 388.0 + 389.0 + 390.0 + 391.0 + 392.0 + 393.0 + 394.0 + 395.0 + 396.0 + 397.0 + 398.0 + 399.0 + 400.0 + 401.0 + 402.0 + 403.0 + 404.0 + 405.0 + 406.0 + 407.0 + 408.0 + 409.0 + 410.0 + 411.0 + 412.0 + 413.0 + 414.0 + 415.0 + 416.0 + 417.0 + 418.0 + 419.0 + 420.0 + 421.0 + 422.0 + 423.0 + 424.0 + 425.0 + 426.0 + 427.0 + 428.0 + 429.0 + 430.0 + 431.0 + 432.0 + 433.0 + 434.0 + 435.0 + 436.0 + 437.0 + 438.0 + 439.0 + 440.0 + 441.0 + 442.0 + 443.0 + 444.0 + 445.0 + 446.0 + 447.0 + 448.0 + 449.0 + 450.0 + 451.0 + 452.0 + 453.0 + 454.0 + 455.0 + 456.0 + 457.0 + 458.0 + 459.0 + 460.0 + 461.0 + 462.0 + 463.0 + 464.0 + 465.0 + 466.0 + 467.0 + 468.0 + 469.0 + 470.0 + 471.0 + 472.0 + 473.0 + 474.0 + 475.0 + 476.0 + 477.0 + 478.0 + 479.0 + 480.0 + 481.0 + 482.0 + 483.0 + 484.0 + 485.0 + 486.0 + 487.0 + 488.0 + 489.0 + 490.0 + 491.0 + 492.0 + 493.0 + 494.0 + 495.0 + 496.0 + 497.0 + 498.0 + 499.0 + 500.0 + 501.0 + 502.0 + 503.0 + 504.0 + 505.0 + 506.0 + 507.0 + 508.0 + 509.0;
return tmp;
}
@compute @workgroup_size(1)
fn computeMain(@builtin(global_invocation_id) id: vec3<u32>) {
output[0] = someFunction();
}
Maybe Safari is trying to perform some expensive optimizations in this massive expression that Chrome skips. These two browsers seem to have different implementation strategies in the WGSL compilers.
6 - Amount of functions possible
Now what about the amount of functions we can have in a module (private space)?
Lets see how far this harness can go:
const fs = [];
for (let i = 0; i < n; i++) {
fs.push(`fn funfunfun${i}(a: f32) -> f32 { return a + ${i}.0; }`);
}
It will produce a bunch of functions with a single argument a just for the
purpose of them doing something on something.
Safari Technology Preview 227
Chrome 140.0.7339.133
Safari is impressive here. Crunching through millions of these without a
problem. Chrome tab crashes at much lower values than this (probably due to the
stringify function, but just assuming here).
7 - Function call depth
How many functions can we call inside each other in WGSL?
Lets see how many of this we can create and call the last one before something breaks:
// How deep can the stack go?
fn levelN() -> f32 { return levelN_minus1(); }
fn levelN_minus1() -> f32 { return levelN_minus2(); }
...
fn levelN_minus${n - 1}() -> f32 { return 1337.0; }
Safari Technology Preview 227
Chrome 140.0.7339.133
Chrome supports a much higher function call depth than Safari. But a 1159 call depth seems a very reasonable limit to play with.
8 - Function statements limit
How many statements can a function have? Lets find out:
fn massiveFunction() -> f32 {
var a = 0.0;
a = 1.0;
a = 2.0;
// Not expressions, but individual statements
...
return a;
}
Safari Technology Preview 227
Chrome 140.0.7339.133
Safari again goes to crazy limits. I would love to be able to see the generated MSL shader.
Chrome feels somewhat flaky here, this limit is the lowest I got it to break, but sometimes it got higher values without a stress up until ~52000.
A table of it all
| Limit Type | Safari Result | Chrome Result | Spec |
|---|---|---|---|
| JS String length | ~4 GiB | ~1 GiB | — |
| Expression depth | 512 | 512 | — |
| Parentheses nesting | 127 | 127 | — |
| Chained expressions (bracket depth) | Hangs tab | ~256 (Metal bracket limit) | — |
| Multiple maxed expressions | Hangs tab | ~3019 (compile fail) | — |
| Max function declarations | > 5 million | ~55719 (compile fail) | — |
| Function call depth | 1159 | 4100 | — |
| Max statements in a function | > 16 million | 49767 | — |
Conclusion
These tests show that real-world WGSL limits often stem from underlying compilers and drivers rather than the spec itself.
For developers pushing creative or extreme workloads, these practical ceilings are just as important as the spec minimums, and in some cases can be far more restrictive.
In particular, hitting the Metal bracket nesting limit (256), is a clear example on how the underlying graphics API can impose additional constraints beyond what WGSL itself enforces.
There are also dramatic differences between Safari and Chrome in the way they handle large expressions. Which suggests very different optimization strategies in their compilers.
I think it would be cool to be able to see the underlying shader being compiled. Maybe the spec could mention groundfloor values for these scenarios, but I am not sure about the implications of it in the grand scheme of WebGPU things.
Ultimately, the spec gives you the floor, but browsers and drivers define the ceiling. If you're pushing WebGPU to its limits, test on real hardware because real bottlenecks exist beyond the spec.
Stay tuned, next post I will try to make a small demo of these limits.
